High Strength and Lightweight: Carbon fiber tubes are exceptionally strong yet lightweight, making them ideal for applications where weight reduction is crucial without compromising on strength.
Stiffness and Rigidity: They offer high stiffness, providing excellent resistance to bending and deformation under load, ensuring structural integrity.
Corrosion Resistance: Carbon fiber tubes are resistant to corrosion and environmental factors, making them suitable for use in harsh conditions.
Design Flexibility: They can be tailored to specific performance requirements through various manufacturing techniques, allowing for customization in diameter, length, and wall thickness.
Fatigue Resistance: Carbon fiber tubes exhibit superior fatigue resistance compared to metals, ensuring long-term reliability and durability in dynamic applications.
|
TECHNICAL DATA SHEET
|
||||
|
Manufacturing Method :
|
Round Carbon Fiber Tube - By Roll Wrapping Process
|
|||
|
Custom Shape Carbon Fiber Tube - By Compression Moulding Process
|
||||
|
Structure
|
UW
|
U= Undirectional Prepreg
|
W= Woven Prepreg
|
|
|
Raw Materials :
|
Carbon Fiber , Epoxy
|
|||
|
Diameter Range O.D.
|
From 6mm O.D. to 300 mm
|
|||
|
Wall Thickness
|
From 0.5mm to 20mm
|
|||
|
Length :
|
From 0.05 Meter to 3.5 Meters
|
|||
|
Colors :
|
Black Or Any Color from RAL ;
|
|||
|
Surface Treament :
|
Matt Finish & Glossy &colors
|
|||
| ID=innder diameter mm | OD=outer diameter mm | length mm | surface |
| 8 | 10 | 1000 | 3k twill /plain/UD |
| 10 | 12 | 1000 | 3k twill /plain/UD |
| 16 | 18 | 1000 | 3k twill /plain/UD |
| 18 | 20 | 1000 | 3k twill /plain/UD |
| 24 | 28 | 1000 | 3k twill /plain/UD |
| 30 | 32 | 1000 | 3k twill /plain/UD |
| 38 | 40 | 1000 | 3k twill /plain/UD |
| 42 | 44 | 1000 | 3k twill /plain/UD |
| This is just some sizes for optional still have more if no you need pls send inquiry to us |
